Precision tapered spindle valves for accurate circuit throttling, gauge dampening, and shut-off under continuous pressures up to 350 BAR.
Falcon high-pressure needle valves [FNV] are two-way seat-type valves used for isolating oil flow and fine fluid circuit trimming. Flow direction is clearly marked on the valve body with an engraved directional arrow.
| Model Code | Port Thread Size | Rated Flow Capacity | Max Working Pressure | Action |
|---|---|---|---|---|
| FNV-08 | 1/4" BSP | 6 LPM | 350 BAR | Inquire |
| FNV-10 | 3/8" BSP | 12 LPM | 350 BAR | Inquire |
| FNV-12 | 1/2" BSP | 20 LPM | 350 BAR | Inquire |
| FNV-16 | 3/4" BSP | 40 LPM | 350 BAR | Inquire |
| FNV-20 | 1" BSP | 65 LPM | 350 BAR | Inquire |
Falcon high-pressure angle needle valves [FANV] feature a 90-degree port orientation for compact panel integration, manifold corners, and gauge isolation where straight piping is impractical.
